CONTROLS
Name | Location | Description |
---|---|---|
Boost | External | Controls the output volume upto +22db. |
Bass | External | Cut/boost the low frequencies. |
Treble | External | Cut/boost the high frequencies. |
Bypass LED Brightness | Internal |
Adjust overall brightness of front LED.
Default setting at minimum (full CCW). |
POWER
9VDC ONLY - CENTER NEGATIVE
This product contains internal circuitry to increase the 9VDC supply to higher voltages for additional headroom.
Applying more than 9VDC can cause damage to this product.
CONSUMPTION
7mA
SWITCHING
TRUE BYPASS
Soft click (1.1KGf) mechanical 3PDT.
