CONTROLS
Name | Location | Description |
---|---|---|
Threshold | External | Controls the gate sensitivity. |
Shift | Internal | Controls the range of the Threshold control. |
GND LIFT | Internal | Ground lift for the KEY input circuit. |
Bypass LED Brightness | Internal |
Adjust overall brightness of front LED.
Default setting at minimum (full CCW). |
POWER
9VDC ONLY - CENTER NEGATIVE
This product contains internal circuitry to increase the 9VDC supply to higher voltages for additional headroom.
This product contains THE overvoltage circuit for 9v input only.
CONSUMPTION
##mA
SWITCHING
TRUE BYPASS
Soft click (1.1KGf) mechanical 3PDT.
