SIGNAL PATH
CONTROLS
Name | Location | Description |
---|---|---|
Gain | External | Controls the amount of distortion |
Level | External |
Controls the output volume.
Start with it at zero, there is a lot of volume on tap. |
Low | External | Cut/boost the bass frequencies. |
Mid | External | Adjust the amount of mid scoop. |
High | External | Cut/boost the bass frequencies. |
Bypass LED Brightness | Internal |
Adjust overall brightness of front LED.
Default setting at minimum (full CCW). |
POWER
9VDC ONLY - CENTER NEGATIVE
This product contains internal circuitry to increase the 9VDC supply to higher voltages for additional headroom.
Applying more than 9VDC can cause damage to this product.
CONSUMPTION
52mA
SWITCHING
TRUE BYPASS
Soft click (1.1KGf) mechanical 3PDT.
